Auto Crane EHC-6 Series
Features and Benefits of the 6006EH Models
- Automatic overload protection system
- Full power extension to 20' 4" (6.2 m)
- Full, continuous power rotation
- Capable of lifting at 100% in all positions on Titan® crane bodies with outriggers
- -14° to +75° boom elevation
- Small sheave
Specifications
| Capacity |
6,000 lb (2,721 kg) |
| Rating |
36,000 ft lb (4.98 ton-m); maximum lifting capacity of 6,000 lb (2,721 kg) at 6 ft (1.83 m) |
| Weight |
1,670 lb (757 kg) |
| Stowed Boom Length |
13' 1" (3.98 m) |
| Extended Boom Length |
20' 4" (6.2 m) |
| Width |
1' 9.75" (.55 m) |
| Height |
2' 11.88" (.91 m) |
| Base Plate Dimensions |
16.75" x 16.75" (.43 m x .43 m) |
| Single Line Speed |
36 ft/min (10.97 m/min) |
| Boom Down |
45-55 seconds (full stroke of cylinder) |
| Boom Retract |
45-55 seconds |
| Full Continuous 360° Boom Rotation |
66-78 seconds |
| Motor |
2.5 hp 24V DC electric hoist motor |
| Cable |
95 ft (28.95 m) of 3/8" (9.52 mm) aircraft quality cable |
| Standards |
OSHA 1910.180, ANSI B30.5 |
| Warranty |
Two-year factory warranty |
You can find further specifications and literature here.
Requirements
- Truck must be equipped with 738896-000 outriggers or equal
- 14,500 GVWR minimum chassis requirement. (Does not include bodies and accessories)
- Battery Information: 575 amp cold cranking rating, 130 minute reserve capacity, maintenance type battery required for 12/24 volt DC operation. 75 amp minimum truck alternator required. Two batteries required.
- Base plate dimensions 16.75 x 16.75
- Bolt holes are 1" in diameter, distance from mid bolt hole to mid bolt hole 14.75 x 14.75
$24,365.00
$29,006.00
